| PE-250-D | 单位-Unit |
※运动空间-Travel range |
|
|
| ±50，±50，±25 | mm |
| ±15，±15，±30 | deg |
※重复定位精度- Repeatability |
|
|
| ±0.6 | μm |
| ±0.2 | μm |
| ±3 | μrad |
| ±9 | μrad |
最小步长- Min. incremental motion |
|
|
| 0.3 | μm |
| 3，3，5 | μrad |
运行速度-Velocity |
|
|
| 1 | mm/s |
| 0.3 | deg/s |
反向间隙-Backlash |
|
|
| 15 | μm |
| 6 | μm |
| 50 | μrad |
| 90 | μrad |
系统刚性- Stiffness |
|
|
| 7 | N/μm |
| 100 | N/μm |
其他性能- Other performance |
|
|
负载能力（正装/任意） -Load(base plate horizontal / any ) | 250/50 | Kg |
断电保持力（正装/任意） -Holding force(base plate horizontal / any ) | 2000/500 | N |
质量-Mass | 17 | Kg |
工作温度-Operating temperature range | 0~50 | ℃ |
供电需求-Main power | 110-220VAC/50-60Hz |
|
|
|
※The motion space refers to the maximum range of motion for a single degree of freedom when the system is in its zero position state.
※The repeatability accuracy refers to the one-way repeatability accuracy, taking one standard deviation.
※During the data acquisition process, no compensation was applied to the motion of each degree of freedom
